The nanobOx Breakthrough
World’s first solid-state nanobubble generation
Our patented solid-state electric field process generates pure nanobubbles directly from dissolved gas in water.
It delivers the highest concentrations of nanobubbles for the lowest power consumption in a single pass of any nanobubble generation system on the market.
What sets us apart
Our technology is built on four core innovations.
Electric Field Nanobubble Generation
Nanobubbles are formed by exposing the water to a precisely controlled electric field.
Pure Nanobubble Formation ……………..
Only nanobubbles (NO microbubbles) are generated in situ using less than 1 % of dissolved gases.
Ultra-low Energy Demand …………………..
Consumes about 1 W per cubic metre of water, which is less than 1 % of the power consumption of conventional nanobubble systems.
High Performance ……………………………………..
Produces very high concentrations of nanobubbles that deliver superior performance across a wide range of applications.
Electric Field Nanobubble Generation
Longer Lasting Oxygen Reservoir
nanobOx air nanobubbles contain 3X more oxygen than standard air nanobubbles.
Breaking the limits of conventional nanobubble generation
nanobOx is the world’s first solid-state nanobubble generator powered by patented electric field technology.
As water passes through a treatment chamber, carefully controlled electric fields cause nanobubbles to nucleate and take up dissolved gas from the water. Continuous exposure to the electric field results in the formation stable nanobubbles (~100 nm diameter) in high concentrations (> 10^9 nb/ml) containing a small fraction of the dissolved gas.
Nanobubbles can be generated from any soluble gas including oxygen, nitrogen, ozone, carbon dioxide and hydrogen.
nanobOx overcomes the limits of conventional nanobubble generation by delivering much higher concentrations of nanobubbles for a fraction of the operating cost regardless of the volume of water treated.
Key Advantages
Low maintenance
Operates with single-phase power at ANY flow rate
Performance is independent of the solids fraction
Highly scalable, modular design
Unique nanobubble properties
Pure Nanobubbles
Most nanobubble generators produce a mix of nanobubbles and microbubbles and should more accurately be described as microbubble-nanobubble generators.
In contrast, nanobOx is engineered to produce only nanobubbles, giving a more concentrated, consistent effect.
Neutral Buoyancy ……….
nanobOx nanobubbles are neutrally buoyant and remain in suspension for hours and days providing much longer-lasting process effects than microbubbles which are buoyant and have a much shorter lifetime.
Longer Lasting Oxygen Reservoir
nanobOx uniquely acts as a molecular filter based on gas solubility. From dissolved air, more oxygen is taken up than nitrogen which is less soluble. The resulting nanobOx air nanobubbles contain 3X more oxygen than standard air nanobubbles and provide reservoir of oxygen for 3X longer.
High Negative Surface Charge (Zeta Potential)
nanobOx nanobubbles carry a high negative surface charge inhibiting coalescence into larger bubbles and making them excellent carriers of positively charged ions and particles as well as very effective cleaning and sanitising agents.
